Thông số kỹ thuật
• Recommended screen size: 39″ (99cm) – 75″ (190cm)
• Max load: 50kg (110lbs) per screen
• Angle adjustment range: up to +/- 45° (between screens)
• VESA® & non-VESA fixings: up to 900mm (35.4″)*
• Pole length: 0.5m (19.7″) up to 3m (118.1″) (can be cut to length)
• Colour options (poles & ceiling mount): Black, White or Chrome
*Refers to maximum vertical fixing dimension for a typical configuration. Correctly sized
interface arms and adaptors will be supplied as necessary to suit the mounting pattern you require.
Tính năng
• Configurable mounting solution available to order to your requirements from stock
• Suitable for landscape or portrait mounting
• Easy to use adjustable adaptor creates an angled join between screens
• Integrated angle guides eliminate the need to measure required angles
• Integrated rail mounting guides ensure the join position is consistent throughout the installation without the need to measure
• Tool-less micro-adjustments for seamless screen alignment
• Arms feature levelling screws to adjust the screen height
• Integrated cable management
• Safety screws help prevent unauthorised removal of screens
• Simple installation with all mounting hardware included
TUV certified
